Delay on Break Relay (DOB)
Upon application of power, the load is energized. When the thermostat or other switch opens or there is a loss of power, the load is de-energized, and the delay period begins.
The compressor will not start again during the delay period. Restart occurs after the delay period has elapsed.
Input:
- Voltage: 8-240 VAC
- Frequency: 5-60 Hz
Output:
- Output Ratings:
- Maximum: 1.5 amp
- Minimum: 40mA
- Inrush: 15 amp in-rush
Time Delay: .03-10 minutes (1.8-600 seconds)
Weight/Dimensions
- Weight: 0.1 lbs.
- Height: 1.25″
- Width: 2″
- Length: 2″
A-1: EAC-501-ADJ
Diversified: AC-503
MARS: 32001, 32387, 32392
Robertshaw: 3310-072
Supco: TD72, TD73
Wagner/DiversiTech: ADB-1
