Description
Universal OEM Replacement Control
Includes wiring harnesses!
ICM2812-KIT
Universal OEM Replacement Control
Includes wiring harnesses!
DETAILS:
The ICM2812-KIT is a universal replacement board that comes packaged with a series of cable harnesses that make it a replacement for the White-Rodgers 50M56U-843 and more than 150 competitive part numbers. See the full cross reference information in the replaces section below.
- Hot Surface Ignition (HSI) control board
- Microprocessor-based
- Monitors timing, trial for ignition, system switches, flame sensing and lockout.
- 100% lockout safety feature
- Compatible with LP or Natural Gas
- LED indication for status and fault codes to aid in troubleshooting
For the board only model, see the ICM2812
WEIGHT/DIMENSIONS:
Weight: 1 lb.
Length: 5.125
Width: 7.0
Height: 1.25
SPECIFICATIONS:
Electrical
- Control voltage: 24 VAC (18-30 VAC)
- Line voltage: 120 VAC
- Operating temperature: -40˚to 175˚F (-40˚to 80˚C)
- HSI Hot Surface Ignitor: 6 amp @ 120 VAC
- Gas Valve: 1.5 amp @ 24 VAC
- Inducer draft motor: 2.2 FLA @120 VAC
- Blower motor: 14.5 FLA @ 120 VAC
Environmental
- Operating Temp Range: -40° to 176°F (-40° to 80°C)
- Humidity Range: 5 to 95% relative humidity (non-condensing)
Replaces:
White-Rodgers: Universal 50M56U-843, and 150+ other models from Goodman, Carrier, Lennox, York, Trane, White Rodgers, Whirlpool, Nordyne and more… See all replacements below:
Goodman/Amana
10207701
10207704
10207706
10207710
10207714
10207717
10207718
10207719
10207720
0130F00005(S)
0130F00006(S)
102077-02
102077-03
102077-04
102077-09
10207720S
B1809926(S)
PCB00109
PCBBF109
PCBBF110(S)
PCBBF112(S)
PCBBF122(S)
PCBBF123(S)
PCBBF132(S)
PCBBF134
PCBBF135
PCBBF136
PCBBF138
Trane/American Standard
CNT02789
CNT02891
CNT03076
CNT03798
CNT03799
CNT05164
CNT05165
D341122P01
D341235P01
D341235P03
D341396P04
D341396P05
D34139P03
Carrier
HK42FZ004
HK42FZ007
HK42FZ008
HK42FZ009
HK42FZ011
HK42FZ016
Lennox
1214201
100925 (-01,-02,-03)
10M93
10M9301
12L6901
17W92
17W9201
23W51
23W5101
30W25
30W2501
32M8801
56L84
56L8401
69M08
69M0801
69M15
69M1501
X4459
X445901
Lennox/Luxaire/York/Coleman/Evcon
G951ADB-1401(C)
G951ADB1402
G951ADB-1403
G951AEB-1403
265901
265902
539617
52537074000
52537077000
031-00662
031-00662-700
031-01250-700
031-01266-700
031-01284-000
031-01973-000
031-09166-000
331-01933-000
331-01972-000
331-09167-000
S1-03100662000
S1-03101250000
S1-03101266000
S1-03101267000
S1-03101267001
S1-03101284000
S1-03101933000
S1-03101972000
S1-03101973000
S1-03109167000
S1-33102956000
S1-33103010000
Heil Quaker/ICP/Thermo Products/Whirlpool
1010806
International Comfort Products
1380686
1380698
1380699
Nordyne
624557
624564
624591
624628
902378
902696
903106
624631(A)
624631(A)
710128A
Rheem/RUUD
695-200
62-22694-xx
62-22732-xx
62-24044-xx
62-24045-01
62-24046-01
62-24084-82
62-24268 (-01,-02,-03)
Texas Instruments
41F-5
61F3
6DT(-1,-2)
Thermo Products
350486
350836
Trane
D330927P01
D330930P01
D330934P01
D340035P01
D340774P01
D341213P01
D341396P01
United Technologies
1012-83-9336A
1012-83-9337A
1012-925 (A,B,C)
1012-933D
Whirlpool
8068142
8068561
8068563
99958174
99958175
White-Rodgers
50A50-110
50A50-111
50A50-112
50A50-113
50A50-130
50A50-131
50A50-142
50A50-143
50A50-205
50A50-206
50A50-207
50A50-208
50A50-209
50A50-210
50A50-215
50A50-216
50A50-229
50A50-230
50A50-240
50A50-241
50A50-245
50A50-285
50A50-286
50A50-288
50A50-295
50A50-296
50A50-298
50A50-405
50A50-406
50A50-407
50A50-408
50A50-438
50A50-471
50A50-472
50A50-473
50A50-474
50A50-475
50A50-571
50A55-143
50A55-241
50A55-245
50A55-250
50A55-285
50A55-286
50A55-288
50A55-289
50A55-3797
50A55-438
50A55-474
50A55-476
50A55-480
50A55-486
50A55-571
50A55-743
50A55-843
50A56-242
50A56-243
50A56-956
50A65-120
50A65-121
50A65-143
50A65-288
50A65-289
50A65-474
50A65-475
50A65-476
50A65-5165
50A65-843
50A66-122
50A66-123
50A66-743
50M56-281
50M56-289
50M56-291
50M56-743
50T35-730
50T35-743
50T55-288
50T55-289
