ICM282A
ICM (Obsolete/Legacy Products)
ICM282A
Carrier OEM Replacement Control
- Low cost replacement for Carrier HK42FZ004/007/008/009/011/013/016
- Controls gas valve, ignitor, blower motor, inducer, humidifier and air cleaner
- Microprocessor-based precision
- Software for enhanced controls operation in counterflow and downflow furnace applications
- Designed for 100% gas shutoff in case of ignition failure
- Twinning compatible with another ICM282A board
- Reverse polarity protection
- Secondary brownout voltage protection
- Compatible with 24 VAC standard thermostat
- Diagnostic fault codes/LED to aid in troubleshooting
Electrical
- Line Voltage Range: 98 to 132 VAC @ 60Hz
- Ignitor: 5A @ 120 VAC
- Cool Blower: 30A, 2 HP, 240 VAC
- Heat: 5A, 1/2 HP, 240 VAC
- Inducer Motor: 4A, FLA-8.0 LRA @ 120 VAC
- Gas Valve: 1.5A @ 30 VAC
Weight/Dimensions
- Weight: 0.55 lb.
- Height: 1.5″
- Width: 8″
- Length: 5″
Carrier: HK42FZ004, HK42FZ007, HK42FZ008, HK42FZ009, HK42FZ011, HK42FZ013, HK42FZ016, 325878-751
ICP: 1176943
Recommended Alternative: ICM282B
