Input

• Voltage: 18 to 30 VAC
  Frequency: 50/60 Hz
• Power Consumption: 1 watt maximum

Output

• Ratings:
  • Type: Relay
  • Form: SPST, normally open
  • Maximum: 1 amp

Time Delay

• Defrost Time: Fixed 10 minutes (+/- 5%)
• Interval Time Between Defrosts: Pin-selectable 30/60/90 min

Weight/Dimensions

• Weight: 0.1 lb.
• Height: 1″
• Width: 3.5″
• Length: 2.875″

Amana: C64301-1, C64310-1

Arcoaire: 32312-00, 3232140

Artesian: 10321-00

Coleman: 3030A374

Essex: 621-1 to 621-11, 621-310

Goodman: B12260-06

Heil Quaker: HQ1052757

Honeywell: ST74A1004, ST74A1020, ST74A1038

ICP: 1052757

Intertherm: 6208800

Lennox: 33G9501

Rheem: 47-21776-01

Robertshaw/Uni-Line: TD-10, DT2-1000

Snyder General: 1395-329

Steveco: 90-621

Therm-O-Disc: 26E-10

Weatherking (Addison): 840-4-5548

White-Rodgers: 90-621
