Installation Guide
download
DETAILS:
- 3-minute, anti-short cycle protection
- Low cost, time and temperature defrost
- Time and temperature terminate
- HOLD input tracks compressor run times
- Test pins reduce test times by 256X
WEIGHT/DIMENSIONS:
Weight: 0.1
Height: 1
Width: 3.5
Length: 2.875
SPECIFICATIONS:
Voltage: 18 to 30 VAC
Frequency: 50/60 Hz
Output:
– Relay, SPST
– N.O.: 1 amp
Anti-Short Cycle Time: 3 minutes
Defrost Time: Fixed 10 minutes
Interval Time Between Defrosts: Pin-selectable 30/60/90 min
Replaces:
Fast: 1093410
Lennox: 86G16
Ranco: DT2
Recommended Alternative:
Function specific; No suggested alternative
